Telefunken TF 39 Three-Pattern Tube Microphone

The TF39 Copperhead Deluxe is an expansion of the “Copperhead” sound with the addition of a dual membrane K67-style capsule, allowing for 3-pattern selection between cardioid, omnidirectional, and figure-8. This added feature set gives the TF39 greater flexibility and options in the studio. Sonically and component-wise, the two microphones are otherwise the same.

The TF39 features a new old stock American-made 5654W vacuum tube, all-brass K67-style capsule, and a premium Swedish-made Lundahl output transformer. These components create a balanced frequency response and natural tonality, making the TF39 a trusty go-to choice.

Key Features:

Designed and assembled by hand in the USA
Pleasant, natural mid range
Extended low frequency response
Stand out antique copper finish
Premium EU-made Lundahl transformer

Applications:

• Natural vocals, bluegrass, folk, and Americana styles
• Electric guitar
• Drums: Kick Out, Overheads, & Room
• Saxophone
• Upright piano
• Banjo

Accessories:
Every TF39 Copperhead Deluxe microphone system comes with a multi pattern M 903 Power Supply, M 803 Tube Microphone Cable, ZC03 Shell Case, M 703 Shock Mount, M 782 Stand Mount, and Microphone Sleeve.

Type: Condenser Pressure Gradient
Capsule: TK67S Center Terminated Diaphragm
Tube Type: 5654W (New Old Stock)
Transformer: Lundahl LL 1935
Polar Pattern: Cardioid
Frequency Range: 20Hz - 20kHz
Sensitivity: 17mV/Pa
THD at 1kHZ at 1Pa (Amplifier): < 0.3%
Output Impedance: < 300 Ω
Maximum SPL (for 1% THD): 130 dB
S/N Ratio: 87 dBA
Self Noise (Amplifier): 7 dBA
Dimensions/Size: 200 mm L x 46 mm Dia
Weight: 650 g
Current Draw from Mains: 50 mA
Power Supply: M 902 PSU - 7 Pin Female XLR Input, 3 Pin Male XLR Output
Cable - M 803: 7 Meter TELEFUNKEN Tube Microphone Cable, 7 Pin Male & Female XLRs
Shock Mount: M 703 - Shock Mount, M 782 - Stand Mount
Flight Case: ZC03 - Light Weight Carrying Case
